Proteins and Peptides

Human Pyruvate kinase isozymes M2 (PKM2), Active Protein

Product Sizes
50 ug
£689.00
RPU58888-50UG
100 ug
£899.00
RPU58888-100UG
1 mg
£3807.00
RPU58888-1MG
About this Product
SKU:
RPU58888
Additional Names:
CTHBP|Cytosolic thyroid hormone-binding protein|M2-PK|M2PK|OIP3|PK3|PKM|PKM1|Pyruvate kinase muscle isozyme|Pyruvate Kinase, Muscle|TCB|THBP1|Thyroid hormone-binding protein 1
Application:
Detection/Quantitation, Tissue Culture
Buffer:
Freeze-dried powder|PBS, pH7.4, containing 0.01% SKL, 5% Trehalose.
CE/IVD:
RUO
Extra Details:
Human Pyruvate kinase isozymes M2 (PKM2), Active Protein is a purified Prokaryotic Protein.
Formulation:
Freeze-dried powder
Immunogen:
Pyruvate kinase isozymes M2 (PKM2)
Molecular Weight:
50kda
Physical State:
freeze-dried
Purity:
>97%
Shipping Conditions:
Blue Ice
Storage Conditions:
-20[o]C Avoid freeze/thaw cycles.
Supplier:
Biomatik
Type:
Proteins, Peptides, Small Molecules & Other Biomolecules: Enzymes
Catalog Protein.JPG
Figure . SDS-PAGE
Figure . Western Blot
Figure. The binding activity of PKM2 with PIN1.Pyruvate Kinase, Muscle (PKM2) is one of four isozymes of pyruvate kinase. In vertebrates there are four isozymes of pyruvate kinase: L (liver), R (erythrocytes), M1 (muscles, hearts and brain) and M2 (only form detectable in early fetal tissue and present in most adult tissues). Pyruvate kinase is the enzyme that catalyzes the final step of glycolysis. It catalyzes the transfer of a phosphate group from phosphoenolpyruvate (PEP) to adenosine diphosphate (ADP), yielding one molecule of pyruvate and one molecule of ATP. Besides, Peptidyl Prolyl Cis/Trans Isomerase NIMA Interacting Protein 1 (PIN1) has been identified as an interactor of PKM2, thus a binding ELISA assay was conducted to detect the interaction of recombinant human PKM2 and recombinant human PIN1. Briefly, PKM2 were diluted serially in PBS, with 0.01% BSA (pH 7.4). Duplicate samples of 100uL were then transferred to PIN1-coated microtiter wells and incubated for 2h at 37°C. Wells were washed with PBST and incubated for 1h with anti-PKM2 pAb, then aspirated and washed 3 times. After incubation with HRP labelled secondary antibody, wells were aspirated and washed 3 times. With the addition of substrate solution, wells were incubated 15-25 minutes at 37°C. Finally, add 50uL stop solution to the wells and read at 450nm immediately. The binding activity of PKM2 and PIN1 was shown in Figure 1, and this effect was in a dose dependent manner.
